| 发动机Engine | 型号Model | Cummins QSK19 | ||
| 额定功率Rated Power | 450KW@1800RPM | |||
| SD60 | SD60CH | ||||||
| 整机Overall | 尺寸Dimension | 10390*4690*7370mm | 9750*6750*4370mm | ||||
| 操作重量Operation Weight | 70630kg | 72550KG | |||||
| 发动机Engine | 型号Model | Cummins QSK19 | Cummins QSK19 | ||||
| 额定功率Rated Power | 450KW@1800RPM | 450KW@1800RPM | |||||
| 速度 Travel Speed |
档位Gear | 1st | 2nd | 3rd | 1st | 2nd | 3rd |
| 前进Forward | 0-3.8km/h | 0-6.8km/h | 0-11.8km/h | 0-3.8km/h | 0-6.8km/h | 0-11.8km/h | |
| 后退Reverse | 0-5.1km/h | 0-9.2km/h | 0-15.8km/h | 0-5.1km/h | 0-9.2km/h | 0-15.8km/h | |
| 托轮数量No. of Carrier Rollers | 2 each side | 2 each side | |||||
| 支重轮数量 No. of Track Rollers | 7 each side | 7 each side | |||||
| 履带板数量Track Shoe Type | 40 each side | 40 each side | |||||
| 履带板宽度Width of Tracek Shoe | 610 mm | 610 mm | |||||
| 轨链节距Pitch | 280mm | 280mm | |||||
| 履带中心距Track Gauge | 2500mm | 2500mm | |||||
| 接地比压Ground Pressure | 130.2Mpa | 130.2Mpa | |||||
| 铲刀 Blade |
铲刀类型Blade Type | 半U铲Semi-U-Blade | 推煤铲Coal blade | ||||
| 铲刀宽度Blade Width | 4690mm | 6750mm | |||||
| 铲刀高度Blade Height | 2250mm | 2515mm | |||||
| 最大铲土深度Max Drop Below Ground | 715mm | 715mm | |||||
| 单齿松土器 Single Shank Ripper |
最大松土深度Max Digging Depth | 14350mm | 14350mm | ||||
| 最大离地提升高度Max Lift Above Ground | 1105mm | 1105mm | |||||
