| KP Series | KP166 | KP206 | KP267H | KP307H |
| Max. Operation Weight(kg) | 16,000 | 20,00 | 26,000 | 30,000 |
| Gound Pressure(kPa) | 200-400 | 200-440 | 250-420 | 250-420 |
| Compaction Width(mm) | 2,270 | 2,270 | 2,750 | 2,750 |
| Climbing Capability(%) | 20 | 20 | 20 | 20 |
| I Speed(km/h) | 0-7 | 0-7 | 0-7 | 0-7 |
| II Speed(km/h) | 0-15 | 0-15 | 0-14 | 0-14 |
| Turing Radius(mm) | 7,500 | 7,500 | 9,000 | 9,000 |
| Tyre Specification(matte) | 11.00-20 | 11.00-20 | 11.00-20 | 11.00-20 |
| Tyre Qty.(f/r) | 4/5 | 4/5 | 5/6 | 5/6 |
| Engine Brand | Weichai | Weichai | Shangchai | Shangchai |
| Emission Standard | China Tier 2 | China Tier 2 | China Tier 4 | China Tier 4 |
| Engine Power(kw) | 105 | 105 | 140 | 140 |
| Volume(mm) | 5200*2270*3350 | 5200*2270*3350 | 5200*2870*3380 | 5200*2870*3380 |
| Driving Pump | Danfoss | Danfoss | Danfoss | Danfoss |
