| KS Series | KS125D | KS145D | KS175HD | KS205HD-2 | KS225HD-2 | KS336HD | KS366HD |
| Operating Weight(kg) | 12,000 | 14,000 | 17,500 | 20,000 | 22,000 | 33,000 | 36,000 |
| Static Linearity(N/cm) | 322 | 391 | 488 | 605 | 644 | 893 | 1,021 |
| Amplitude(mm) | 1.85/0.83 | 1.85/0.83 | 1.9/0.9 | 1.98/0.91 | 1.98/0.99 | 2.1/1.2 | 1.9/1.0 |
| Vibration Frequency(Hz) | 30/34 | 30/34 | 28/33 | 28/32 | 28/32 | 28/32 | 28/32 |
| Centrifugal Force (kN) | 280/162 | 315/190 | 350/245 | 400/270 | 415/285 | 680/540 | 805/550 |
| Drum Width(mm) | 2,130 | 2,130 | 2,110 | 2,150 | 2,150 | 2350 | 2350 |
| Drum Diameter(mm) | 1,533 | 1,533 | 1,540 | 1,550 | 1,550 | 1700 | 1700 |
| Speed Range(km/h) | 0-9 | 0-9 | 0-9 | 0-9 | 0-9 | 0-9 | 0-9 |
| Climbing Capability(%) | 45 | 45 | 45 | 45 | 45 | 45 | 45 |
| Turing Radius(mm) | 6,500 | 6,500 | 6,500 | 6,500 | 6,500 | 7500 | 7500 |
| Engine Brand | Weichai | Weichai | Weichai | Weichai | Weichai | Weichai | Weichai |
| Emission Standard | China Tier 2 | China Tier 2 | China Tier 3 | China Tier 3 | China Tier 3 | China Tier 3 | China Tier 3 |
| Engine Power(kW) | 105 | 105 | 140 | 140 | 140 | 276 | 276 |
| Volume(mm) | 5970*2290*3150 | 5970*2290*3150 | 6380*2300*3150 | 6380*2430*3150 | 6380*2430*3150 | 6920*2690*3500 | 6920*2690*3500 |
| Hydraulic System | Danfoss | Danfoss | Danfoss | Danfoss | Danfoss | Danfoss | Danfoss |
