| Basic paving width | 2500mm |
| Maximum paving width | 6000mm |
| Evenness | 3mm/3m |
| Model | 型号 | KAP60 |
| Basic paving width | 基本摊铺宽度 | 2500mm |
| Maximum paving width | 最大摊铺宽度 | 6000mm |
| Maximum paving thickness | 最大摊铺厚度 | 250mm |
| Minimum paving thickness | 最小摊铺厚度 | 10mm |
| Driving speed | 行驶速度 | 1.55-4.62km/h |
| Working speed | 摊铺速度 | 2.03-6.07km/h |
| Evenness | 平整度 | 3mm/3m |
| Maximum productivity | 最大理论生产率 | 220t/h |
| Hopper capacity | 料斗容积 | 10t |
| Max. Climb Capability | 最大爬坡能力 | 20% |
| Weight | 整机质量 | 11-12t |
| Dimensions | 外形尺寸 | 5820*2995*3480mm |
| Transport dimensions | 运输尺寸 | 5520*2494*2450mm |
| Engine brand | 发动机品牌 | CUMMINS QSB3.9-C80-31 |
| Rated power | 额定功率 | 60kW@2200rpm |
| Diesel tank capacity | 柴油箱容量 | 143L |
