| Engine brand | Weifang80hp/Sida EURO V |
| Engine Intake Mode | Turbocharged |
| 型号 Model |
604轮式拖拉机 604 Wheeled Tractor |
804轮式拖拉机 804 Wheeled Tractor |
1004轮式拖拉机 1004 Wheeled Tractor |
1204轮式拖拉机 1204 Wheeled Tractor |
1504轮式拖拉机 1504 Wheeled Tractor |
| 驱动模式 Drive Mode |
四驱/二驱 Four-wheel drive/Two-wheel drive |
四驱/二驱 Four-wheel drive/Two-wheel drive |
四驱/二驱 Four-wheel drive/Two-wheel drive |
四驱/二驱 Four-wheel drive/Two-wheel drive |
四驱/二驱 Four-wheel drive/Two-wheel drive |
| 整机尺寸(长*宽*高) Overall Dimension（length*width*height） |
3300*1500*1970 | 3300*1500*1970 | 3700*1500*2750 | 4600*2200*2980 | 4600*2200*2980 |
| 轴距 Wheelbase |
2000 | 2000 | 2000 | 2650 | 2650 |
| 常用轮距(前轮/后轮) Common wheel base(front/rear) |
1200 | 1200 | 1200 | 1600 | 1600 |
| 轮距(前轮/后轮) Wheelbase |
1100-1300可调 1100-1300 Adjustable |
1100-1300可调 1100-1300 Adjustable |
1100-1300可调 1100-1300 Adjustable |
1500-2200可调 1500-2200 Adjustable |
1500-2200可调 1500-2200 Adjustable |
| 最小离地间隙 Min. ground clearance |
380前桥底部 Buttom of Front Axle |
380前桥底部 Buttom of Front Axle |
380前桥底部 Buttom of Front Axle |
470前桥底部 Buttom of Front Axle |
470前桥底部 Buttom of Front Axle |
| 后桥 Rear axle |
TYE大桥(8+8) 8+8 Bridge Shuttle Side Gear |
TE大桥(8+8) 8+8 Bridge Shuttle Side Gear |
TE大桥(8+8) 8+8 Bridge Shuttle Side Gear |
TB大桥(12+12) 12+12 Bridge Shuttle Side Gear |
TB大桥(12+12) 12+12 Bridge Shuttle Side Gear |
| 最高设计理论速度 Max. theoretical design speed |
42 | 42 | 42 | 48 | 48 |
| 发动机厂家 Engine brand |
潍坊60马力/四达(欧五) Weifang80hp/Sida EURO V |
潍坊80马力/四达(欧五) Weifang80hp/Sida EURO V |
潍坊100马力/四达(欧五) Weifang100hp/Sida EURO V |
潍坊120马力/四达(欧五) Weifang120hp/Sida EURO V |
潍坊150马力/四达(欧五) Weifang150hp/Sida EURO V |
| 发动机进气方式 Engine Intake Mode |
涡轮增加 Turbocharged |
涡轮增加 Turbocharged |
涡轮增加 Turbocharged |
涡轮增加 Turbocharged |
涡轮增加 Turbocharged |
| 发动机气缸数 Number of Cylinders |
4 | 4 | 4 | 4 | 6 |
| 发动机标准功率 Standard Engine Power |
44.1 | 59 | 76.3 | 88.3 | 103 |
| 发动机转速 Standard Engine Speed |
2400 | 2400 | 2400 | 2400 | 2400 |
| 轮胎型号 Tire Type |
前轮：6.5-16 后轮：11.2-24 Front wheel: 6.5-16 Rear wheel: 11.2-24 |
前轮：8.3-20 后轮：12.4-28 Front wheel: 8.3-20 Rear wheel: 12.4-28 |
前轮：8.3-20 后轮：12.4-28 Front wheel: 8.3-20 Rear wheel: 12.4-28 |
前轮：11-24 后轮：16.9-30 Front wheel: 11.2-24 Rear wheel: 16.9-30 |
前轮：11.2-24 后轮：16.9-30 Front wheel: 11.2-24 Rear wheel: 16.9-30 |
| 悬挂装置型式 Suspension Type |
后置三点悬挂 Rear three-point suspension |
后置三点悬挂 Rear three-point suspension |
后置三点悬挂 Rear three-point suspension |
后置三点悬挂 Rear three-point suspension |
后置三点悬挂 Rear three-point suspension |
| 液压输出组数 Number of Hydraulic Output Groups |
三组 Three Groups |
三组 Three Groups |
三组 Three Groups |
三组 Three Groups |
三组 Three Groups |
| 工作表装置安全阀全开压力 Working Device Safety Valve Full Open Pressure |
17.5-18 | 17.5-18 | 17.5-18 | 17.5-18 | 17.5-18 |
| 动力输出轴标准转速 Power Output Shaft Standard Speed |
540/720 | 540/720 | 540/720 | 760/850 | 760/850 |
| 备注： Notice |
单油箱，配备安全框架，有6个前配重和2个后配重砝码 Single fuel tank, equipped with safety frames, with 6 front counterweights and 2 rear counterweights |
单油箱，配备安全框架，有6个前配重和2个后配重砝码 Single fuel tank, equipped with safety frames, with 6 front counterweights and 2 rear counterweights |
单油箱，配备安全框架，有6个前配重和2个后配重砝码 Single fuel tank, equipped with safety frames, with 6 front counterweights and 2 rear counterweights |
双油箱，配备安全框架，有8个前配重和4个后配重砝码 Double fuel tanks, equipped with safety frames, with 8 front counterweights and 4 rear counterweights |
双油箱，配备安全框架，有8个前配重和4个后配重砝码 Double fuel tanks, equipped with safety frames, with 8 front counterweights and 4 rear counterweights |
